– QUICK SPECIFICATION SHEET –
ELECTRIC MAINS
DIMENSIONS
Approximate dimensions and footprints of the Spirit are shown in the illustrations. The black circles are the anti-vibration feet. The optimal countertop feedthroughs are within the grey squares. Check the pre-install guide for recommended feedthrough sizes.
WEIGHT
The countertop should provide a solid base to carry the full weight of the machine: roughly 90kg for the Duette and 125kg for the Triplette.
NOTES
Water supply from a water treatment system should be within 1.5m (5ft) of the machine. The water supply hose that comes with the machine has a half ball at the end of the 3/8″ nut connector. Discharge should not be further away than 1.5m, have an internal diameter of at least 40mm (1.5″) and should be fitted with a trap. There must be space nearby to locate the water pump with its electrical motor.
SHIPPING CRATES
Download an overview of the shipping crate dimensions and weight by clicking here.
SPIRIT VIDEOS
_______________
Check out our YouTube channel for our video guides, or click here.
From installation and user instructions, to service and upgrade walk throughs.
SPIRIT PRE-INSTALLATION GUIDE
_______________
Pre-install guide: All the details you need to know to prepare the workspace.
SPIRIT INSTALLATION
_______________
A detailed description of all the practical ins and outs for installation and operation.
SPIRIT USER MANUAL
_______________
All the operational details about the machine are described here extensively.
SPIRIT TECHNICAL
_______________
The technical manual is available for all trained mechanics.
To request a copy, send an email to support@keesvanderwesten.com.
We kindly ask to include:
1. Your name (additional company name is welcome)
2. the serial number of the machine
SPIRIT PARTS LIST
_______________
Need spares or replacements parts?
Make sure you order what you need by using this document.
